Ex-Linear light fittings for fluorescent lamps

eLLK 92 18 W – 58 W / eLLM 92 18 W – 36 W (Zone 1, 2, 21, 22)

The classic lighting solution in hazardous areas

The eLLK 92 linear luminaire se-ries for fluorescent lamps com-bines the latest lighting technol-ogy with the requirements of a harsh and hazardous envi-ronment. This luminaire series is available in various sizes as a ceiling mounted light fitting (eLLK) and as a pole-mounted light fitting (eLLM).

Long-term safety

The luminaires of this robust lighting series with plastic en-closures are equipped with a

highly-efficient electronic ballast that features a reliable EOL cir-cuit. Thus, the lamps are

checked for proper operation and shut down safely in the event of a malfunction at the

end of their service life. In addi-tion, the dual-channel structure of the electronic ballasts ena-bles the safe operation of the second lamp if one lamp fails.

Versatile

The wide input voltage range and major international approv-als enable the worldwide use of this successful luminaire series.

Simple and cost-effective installation

In conjunction with the gener-ously dimensioned terminal compartment, the standard, sin-gle-ended through-wiring allows a cost-effective installation. The double-sided locking facility with 10, 20 or 24 latch points al-lows the protective bowl to be hinged on both sides meaning that the fitting can be mounted on either side.

Just in case: the emergency lighting version

Safety is always our top priority. This is why we also supply the eLLK 92 light fitting series with a built-in V-CG-S module. These luminaires with individual moni-toring can be connected to a CEAG emergency lighting supply system. Another option for operation with central battery emergency lighting systems (ZB) is the DCA version without individual monitoring. In the emergency mode, one lamp is turned off (AC / DC monitoring), thus re-ducing the required battery power. The NE variants (Section 2.4) are also available for use as emergency light fittings with a self-contained battery unit.

Ready for LED-use

Our new version “LED-Ready” is equippt with all wiring for use of the LED-module. Those luminaires can

International certification

Special versions according to the NEC standards are available for the use on the American market. CSA certification for the types of luminaires eLLK 92 2217 (2 x 17 W) and eLLK 92 4232 (2 x 32 W) allows their use there. Other country-specific approv-als, such as for Brazil or the new Eurasian Conformity (EAC) for placing them on the market

in Russia, Belarus and Kazakh- stan, are available.

Features

• Retrofitting of existing eLLK/M 92 018/18 or

eLLK/M 92036/36 linear luminaires (latest version) is possible

• Standard dual channel ballast with EOL monitoring

• Can be used with CEAG LED module

• Double-sided central locking facility

• Safety interlocking system due to an integrated forced

isolating switch

• Safety standard IP66

• Connection to CEAG emergency light monitoring systems

possible (V-CG-S/DCA)
