EATON - CROUSE HINDS PFME LED floodlight PFME-60L-Y-UNV1

Written By Distributor Lampu Philips PT Savont Varavi IND on Selasa, 12 September 2023 | 18.21

PFME LED floodlights

The PFME LED family
PFME LED floodlights are the perfect replacement for indoor/outdoor
light industrial areas.

Model
Typical
lumensA Watts
Lumens per
watt
Equivalent
HID
luminaire
PFME15L 15,400 120.2 128.1 500W
PFME30L 30,700 242.2 126.8 750W-1000W
PFME60L 62,000 484.5 128.0 1500W+
PFME75L 79,000 603.5 130.9 1500W+

Applications:
• Non-hazardous locations with mounting
heights up to 60 feet
• Light industrial, platforms, loading docks,
tunnels, indoor/outdoor spotlighting,
outdoor general area lighting and areas
requiring frequent on-and-off of lights
• Locations requiring continuous and
consistent light levels in extreme ambient
temperatures
• Where extremely wet, dusty, hot and/or
cold conditions exist

Features:
• Instant illumination and restrike
• Serviceable drivers
• Better visibility with crisp, white light
• Cold temperature operation / no warm-up
required
• Energy-efficient – up to 130 lumens per
watt
• Contains no mercury or other hazardous
substances
• Shock- and vibration-resistant solid-state
luminaires
• No filaments or glass components
• Operating ambient:
-30°C to +45°C
• Full cut-off with no wasted light above the
fixture

Certifications and
compliances:
• Wet locations, IP65
• UL standard: UL1598
• CSA standard: CSA C22.2 No. 250
Standard materials:
• Housing and heat sink – extruded
aluminum 6063
• Lens and optic assemblies –
polycarbonate

Photometrics:
• Refer to www.eaton.com (under the
Resources tab of each product family) for
specific photometric IES files

Electrical ratings:
UNV1 15L 30L 60L 75L
Input power (watts) 120.2 242.2 484.5 603.5
Input amps at 120-277 VAC 0.45-1.06A 0.91-2.10A 1.82-4.21A 2.28-5.27A
Total Harmonic Distortion (THD) <15% <15% <15% <15%
Power factor >0.90 >0.95 >0.95 >0.95
Voltage range at 50/60 Hz
UNV1 120-277 VAC; 127-400 VDC
PFME75L
PFME30L
PFME60L
PFME15L
UNV34 15L 30L 60L 75L
Input power (watts) 120.2 242.2 484.5 603.5
Input amps at 277-480 VAC 0.27-0.49A 0.55-0.97A 1.11-1.93A 1.38-2.41A
Total Harmonic Distortion (THD) <20% <20% <20% <20%
Power factor >0.90 >0.90 >0.90 >0.90
Voltage range at 50/60 Hz
UNV34 277-480 VAC

PFME 30L W Y -UNV1 -66
Ordering information:
Light source / intensity
15L 15,400 lumen LED
30L 30,7000 lumen LED
60L 62,000 lumen LED
75L 79,000 lumen LED
Voltage
UNV1 120-277 VAC; 127-400
VDC
UNV34 277-480 VAC
Optical distribution
66 Standard 120° angle
22 Narrow 25° angle
Color temperature
BLANK 5000K, 80 CRI (cool white)
WB 3000K, 80 CRI (warm white)
NB 4000K, 80 CRI (neutral white)
Part number example
PFME30LWY-UNV1-66
Mounting
Y Yoke

Accessories (ordered separately):
Mounting and photocell (ordered separately)
PFME-POLE-MNT Pole mount kit for 15L-75L models
PFME-PHOTOCELL Photocell for 15L-75L models
Replacement driver kits (ordered separately)
PFME-15L-UNV1-DRIVER-KIT UNV1 driver for 15L
PFME-15L-UNV34-DRIVER-KIT UNV34 driver for 15L
PFME-30L-UNV1-DRIVER-KIT UNV1 driver for 30L
PFME-30L-UNV34-DRIVER-KIT UNV34 driver for 30L
PFME-60L-UNV1-DRIVER-KIT UNV1 driver for 60L
PFME-60L-UNV34-DRIVER-KIT UNV34 driver for 60L
PFME-75L-UNV1-DRIVER-KIT UNV1 driver for 75L
PFME-75L-UNV34-DRIVER-KIT UNV34 driver for 75L
Guards and visors (ordered separately)
Model Cat. #
Guard Qty. Cat. #
Visor Qty.
15L PFME-WIREGUARD-1 2 PFME-VISOR-1 2
30L PFME-WIREGUARD-2
2 PFME-VISOR-2
2
60L 4 4
75L 5 5
